Environmental Product Declaration
Solar Gard® Clear Safety films up to 14 mil
Environmental Product Declaration (EPD) for Solar Gard® Clear Safety films up to 14 mil, manufactured by Solar Gard Saint-Gobain. Declaration SmartEPD-2025-059-0383-01, prepared according to Smart EPD® Part A Product Category Rules for Building and Construction Products and Services, 1000, v1.01, valid until March 28, 2030.
- Declared unit
- 1 m2 of product
- Valid until
- March 28, 2030
- PCR
- Smart EPD Part A Product Category Rules for Building and Construction Products and Services, 1000, v1.01
Declaration details
- Manufacturer
- Solar Gard Saint-Gobain
- Program operator
- Smart EPD
- Declaration number
- SmartEPD-2025-059-0383-01
- Date of issue
- March 28, 2025
- Valid until
- March 28, 2030
- Product category rules (PCR)
- Smart EPD® Part A Product Category Rules for Building and Construction Products and Services, 1000, v1.01 (version 1.01)
- Standard
- ISO 14025:2006 and ISO 21930:2017
- Declared unit
- 1 m2 of product
- System boundary
- Cradle to gate with other options (A1 - A3, A4, A5, C1 - C4)
- Product specificity
- Product Specific
- Manufacturing specificity
- Facility Specific
- Manufacturing plant
- Solar Gard (4540 Viewridge Ave, San Diego, CA 92123, USA)
- Product category
- Openings › Glazing
- Product service life
- 12 years
- Verifier
- Rifat Karim, Independent Consultant
- LCA software
- GaBi 8.0
- Program instructions
- Smart EPD General Program Instructions v.1.0, November 2022
Life cycle assessment results
Results per 1 m2 of product.
Environmental Impact Assessment Results
| Indicator | Unit | A1-A3 | A4 | A5 | C1 | C2 | C3 | C4 |
|---|---|---|---|---|---|---|---|---|
| GWP-total | kg CO2 eq | 5.36e+0 | 1.36e-2 | 3.81e-1 | 4.00e-4 | 3.65e-3 | 2.11e-2 | 4.06e-1 |
| GWP-fossil | kg CO2 eq | 5.40e+0 | 1.36e-2 | 3.36e-1 | 4.00e-4 | 3.65e-3 | 1.59e-2 | 4.06e-1 |
| GWP-biogenic | kg CO2 eq | -4.91e-2 | 0 | 3.44e-2 | 2.58e-6 | 1.66e-6 | 5.00e-3 | 2.32e-5 |
| GWP-luluc | kg CO2 eq | 2.58e-3 | 0 | 9.86e-3 | 5.65e-7 | 1.38e-6 | 1.78e-5 | 2.28e-6 |
| ODP | kg CFC 11 eq | 6.40e-7 | 1.64e-7 | 4.25e-8 | 2.22e-11 | 8.98e-10 | 2.28e-9 | 1.30e-9 |
| AP | kg SO2 eq | 1.56e-2 | 5.95e-3 | 1.28e-3 | 1.88e-6 | 2.78e-5 | 1.08e-4 | 1.27e-4 |
| EP | kg N eq | 5.10e-4 | 3.46e-4 | 7.43e-5 | 4.70e-8 | 1.71e-6 | 6.33e-6 | 1.65e-5 |
| POCP | kg O3 eq | 7.05e-4 | 3.56e-4 | 6.07e-5 | 5.33e-8 | 1.88e-6 | 6.41e-6 | 8.65e-6 |
Resource Use Indicators
| Indicator | Unit | A1-A3 | A4 | A5 | C1 | C2 | C3 | C4 |
|---|---|---|---|---|---|---|---|---|
| PERE | MJ | 4.94e+0 | 7.59e-2 | 3.99e-1 | 6.00e-4 | 8.12e-4 | 1.43e-2 | 2.44e-3 |
| PERM | MJ | 2.19e-1 | 0 | 8.12e-3 | 0 | 0 | 0 | 0 |
| PERT | MJ | 5.16e+0 | 7.59e-2 | 4.07e-1 | 6.00e-4 | 8.12e-4 | 1.43e-2 | 2.44e-3 |
| PENRE | MJ | 7.19e+1 | 1.17e+1 | 4.44e+0 | 5.90e-3 | 7.01e-2 | 2.35e+0 | 1.37e-1 |
| PENRM | MJ | 1.24e+1 | 0 | 5.19e-1 | 0 | 0 | -1.99e+0 | 0 |
| PENRT | MJ | 8.44e+1 | 1.17e+1 | 4.97e+0 | 5.90e-3 | 7.01e-2 | 3.59e-1 | 1.37e-1 |
| ADP-fossil | MJ | 8.44e+1 | 1.17e+1 | 4.96e+0 | 5.90e-3 | 7.01e-2 | 3.59e-1 | 1.37e-1 |
| SM | kg | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| RSF | MJ | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| NRSF | MJ | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| FW | m3 | 4.60e-2 | 6.75e-4 | 4.59e-3 | 1.00e-3 | 8.37e-6 | 1.35e-4 | 7.71e-5 |
| RE | MJ | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
Waste and Output Flow Indicators
| Indicator | Unit | A1-A3 | A4 | A5 | C1 | C2 | C3 | C4 |
|---|---|---|---|---|---|---|---|---|
| HWD | kg | 3.27e-2 | 2.98e-5 | 1.62e-3 | 3.23e-9 | 1.74e-7 | 5.48e-7 | 5.62e-7 |
| NHWD | kg | 1.53e+0 | 2.78e-1 | 1.11e-1 | 2.00e-4 | 4.87e-3 | 2.68e-2 | 3.15e-1 |
| RWD | kg | ND | ND | ND | ND | ND | ND | ND |
| HLRW | kg | 1.06e-4 | 8.18e-5 | 1.02e-5 | 2.10e-8 | 4.52e-7 | 1.20e-6 | 5.17e-7 |
| ILLRW | kg | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| CRU | kg | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| MFR | kg | 4.17e-2 | 0 | 1.10e-2 | 0 | 0 | 8.66e-2 | 0 |
| MER | kg | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| MNER | kg | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| EEE | MJ | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| EET | MJ | 0 | 0 | 0 | ND | 0 | 0 | 0 |
Carbon Emissions and Removals
| Indicator | Unit | A1-A3 | A4 | A5 | C1 | C2 | C3 | C4 |
|---|---|---|---|---|---|---|---|---|
| BCRP | kg CO2 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| BCEP | kg CO2 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| BCRK | kg CO2 | -5.34e-3 | 0 | 0 | 0 | 0 | 0 | 0 |
| BCEK | kg CO2 | 0 | 0 | 5.34e-3 | 0 | 0 | 0 | 0 |
| BCEW | kg CO2 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| CCE | kg CO2 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| CCR | kg CO2 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| CWNR | kg CO2 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
ND = not declared. Life cycle modules: A1-A3 product stage, A4-A5 construction process, B use stage, C end of life, D benefits and loads beyond the system boundary.
Material composition
| Material/Component Category | Origin | % Mass |
|---|---|---|
| Polyethylene Terephthalate (PET) Film | 59 | |
| Acrylic Adhesive | 11 | |
| Coating | 0.004 | |
| Release Liner (PET) | 30 |
| Packaging material | Origin | Mass (kg) |
|---|---|---|
| Cardboard Box | 0.0015 | |
| Cardboard Core | 0.0012 | |
| LDPE Sleeves | 0.00003 | |
| End Plug - Cardboard or HDPE | 0.0001 | |
| End Plates - MDF | 0.0009 | |
| Pallet - Wood | 0.004 | |
| Shrink Wrap - LLDPE | 0.0004 |
| Biogenic carbon content | kg C per m2 |
|---|---|
| Biogenic carbon content in product | 0 |
| Biogenic carbon content in accompanying packaging | 0.00359 |
Hazardous substances
No regulated hazardous or dangerous substances are included in this product.
Scenarios
Transport to the building site (A4)
- Vehicle type
- Truck
- Transport distance
- 2923 km
- Weight of products transported
- 0.082 kg
- Packaging mass
- 0.0425 kg
End of life (C1-C4)
- Collected separately
- 0.012 kg
- Collected with mixed construction waste
- 0.070 kg
- Recycling
- 0.0123 kg
- Landfill
- 0.0377 kg
- Incineration with energy recovery
- 0.0328 kg
- Product or material for final disposal
- 0.0819 kg
Product description
The Solar Gard range of architectural heavy gauge safety and security films enhances the performance of existing glass and facades in homes and commercial buildings. These films provide enhanced safety and security, improve visual comfort, and protect against harmful UV radiation.
Solar Gard heavy gauge safety and security films consist of multiple layers of clear polyethylene terephthalate (PET). Solar Gard heavy gauge safety and security films range is available in various performance levels and shades to meet diverse customer needs and specifications.
Product Benefits
Holds broken glass shards in place
Reduces risks associated with broken glass and airborne debris
Provides exceptional blast and impact-resistant capabilities
Increases occupants’ wellbeing and productivity
Shields occupants from harmful UVA and UVB rays with an SPF equivalent of 285+
Mitigates the negative effects of UV radiation on interior finishes
All Solar Gard films undergo rigorous inspection and endurance testing to ensure durability and customer satisfaction. To ensure performance, we conduct regular testing of our safety and security films against industry standards. Solar Gard also offers product warranties, many of which cover a lifetime for residential applications.
In total this EPD covers three (3) clear safety and security films. The reference product for the group of products covered in this EPD is Solar Gard ARMORCOAT 14 MIL CLEAR (supplied as roll of 1.52 m / 60” wide and 30.5 m / 100 ft long).
The Performance Specifications table in the Further Information section provides an overview of the solar control film product references covered in this EPD.
Solar Gard can provide detailed data for any product covered by this EPD, if requested.
↩
Interpretation
For GWP, the majority of contribution to this environmental impact is from the production modules (A1 – A3). This is primarily because the sources of greenhouse gas emissions are predominant in this part of the life cycle. CO2 emissions are generated upstream from the production of electricity and is also released on site by the combustion diesel and natural gas. Other sections of the life cycle also contribute to the GWP. However, the production modules contribute to over 80% of the contribution. Emissions from waste disposal in A5 (disposal after installation) and C (transport and disposal at the end of life) generate the second highest percentage of greenhouse gas emissions.
LCIA results are relative expressions and do not predict impacts on category endpoints, the exceeding of thresholds, safety margins or risks. EPDs are comparable only when they follow the same PCR, functional unit and system boundary. The full EPD (PDF) contains the methodology, scenario assumptions and verification statement.
